3.2 Ton Single Phase Electric Hoist 50Hz / 60Hz Single Phase Electric Chain Hoists 220V IP55 Motor

Name: 3.2 Ton Single Phase Electric Hoist 50Hz / 60Hz Single Phase Electric Chain Hoists 220V IP55 Motor
Brand: Zhejiang Junchi Machinery Co., Ltd
SKU: RY 0302
Price: 25.00 USD
Availability: InStock

Brand Name:	KOEO
Model Number:	RY 0302
MOQ:	1 Set
Price:	USD 680-1,050 / Set
Payment Terms:	T/T,L/C
Supply Ability:	300 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang, China

Certification:

CE, ISO 9001:2015

Load Capacity:

3200 Kg (3.2 Ton)

Lifting Speed:

7/2.3 M/min

Lifting Height:

4 M (standard, Customizable)

Motor Power:

2.2 KW

Motor Voltage:

220V Single Phase 50Hz / 60Hz

Protection Class:

IP55

Insulation Class:

Class F (155°C)

Brake Type:

Dual Electromagnetic DC Brake

Load Chain Type:

G80 Grade Alloy Steel

Chain Diameter:

8.0 Mm

Chain Falls:

Headroom Design:

Low Headroom Compact Body

Control Voltage:

36V Low Voltage Pendant Control

Duty Rating:

A3 / M5 (FEM/ISO)

Net Weight:

55 Kg

Noise Level:

≤ 74 DB

Finish:

Electrostatic Powder Coating

Plug Type:

Standard 220V Single Phase Plug

Packaging Details:

KOEO branded heavy-duty plywood case with foam padding and moisture-proof wrapping, export-grade reinforced carton

Highlight:

3.2 Ton Single Phase Electric Hoist

Single Phase Electric Hoist 50Hz

60Hz Single Phase Electric Chain Hoists

Product Description

3.2 Ton Single Phase Electric Chain Hoist 220V IP55 Motor G80 Alloy Chain Low Headroom Dual Brake

The KOEO RY 0302 is the most powerful single phase electric chain hoist in the KOEO lineup, delivering an impressive 2-ton lifting capacity on standard 220V household electricity. With a 2.2 kW single phase motor, dual electromagnetic DC brake system, G80 alloy steel chain, and low headroom compact design, the HHBB-02S brings heavy-duty lifting performance to workshops, garages, and small factories that lack three-phase industrial power.

🔧 Key Features

3.2Ton Capacity on 220V Single Phase: Powerful 2.2 kW single phase motor delivers full 3.2-ton lifting from any standard 220V outlet. Eliminates the need for expensive three-phase power installation in small workshops.
Dual Electromagnetic DC Brake System: Twin independent DC brakes provide redundant safety. Both brakes engage instantly upon power-off, holding the full 3.2-ton load with zero slippage.
G80 Alloy Steel Chain (Ø8.0 mm): Heavy-duty calibrated chain with 4:1 safety factor, designed for the high load demands of 3.2-ton lifting cycles.
Low Headroom Compact Design: Space-optimized body maintains the lowest possible headroom profile for a 3.2-ton single phase hoist.
IP55 Enclosed Motor: Robust dust-tight and water-jet protection with Class F (155°C) insulation for continuous workshop duty.
Overload Protection & Dual Limit Switches: Comprehensive safety system protects against overload and over-travel in both directions.
36V Pendant Control: Industrial-grade pendant with emergency stop for safe operation during heavy lifts.

📋 Technical Specifications

Parameter	Specification
Load Capacity	3200 kg (3.2 Ton)
Lifting Speed	7/2.3 m/min
Lifting Height	4 m (standard, customizable)
Motor Power	2.2 kW
Power Supply	220V Single Phase 50Hz / 60Hz
Chain Type	G80 Grade Alloy Steel, Ø8.0 mm
Chain Falls	1
Brake Configuration	Dual Electromagnetic DC Brake
Motor Protection	IP55
Insulation Class	Class F (155°C)
Duty Rating	A3 / M4 (FEM/ISO)
Control Type	36V Pendant with Emergency Stop
Net Weight	55 kg
Noise Level	≤ 74 dB
Finish	Electrostatic Powder Coating

🏭 Applications

The HHBB-02S is the go-to 2-ton lifting solution for auto body shops, small steel fabrication workshops, machinery repair facilities, agricultural equipment dealerships, and commercial warehouse operations where single phase electricity is the only power source. The dual brake system provides an extra margin of safety for heavy lifts in cramped workshop spaces. Compatible with jib cranes, monorail trolley systems, and fixed ceiling mounts.

✅ Quality & Certification

CE Certified – Compliant with EU Machinery Directive 2006/42/EC
ISO 9001:2015 Quality Management System
4:1 safety factor on all load-bearing components
100% factory load-tested at 1.25x rated capacity (4 tons) before shipment
G80 chain certified to EN 818-7 standard

📦 Packaging & Delivery

Each hoist is packed in a KOEO-branded heavy-duty plywood case with reinforced foam padding and moisture-proof wrapping. Export-grade outer carton ensures safe transport. Standard delivery: 7-10 working days for stock models, 15-25 days for bulk production orders.
